11. TECHNICAL DATA
11.1 Rating plate
Model IKK64681FB PNC 949 597 916 00
Typ 62 B4A 06 AA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in Germany
Ser.Nr. ................. 7.35 kW
AEG
11.2 Cooking zones specification
Induction cooking
surface
Nominal power
(maximum heat
setting) [W]
PowerBoost [W] PowerBoost maxi‐
mum duration [min]
Single triangle 1150 1600 10
Standard cooking
zone
2000 3000 10
Centre zone 4200 - -
Vertical zone 3200 - -
Horizontal zone 4100 - -
The power of the cooking zones can be different from the data in the table. It changes
with the material and dimensions of the cookware.
Cookware sizes
Bridge mode Cookware dimension (min‐
imum)
Cookware dimension
(maximum)
Single triangle 100 mm 160 mm
Standard cooking zone 160 mm 210 mm
Centre zone 240 mm 350 mm
Vertical zone The area of 3 single trian‐
gles
The area of 4 single trian‐
gles
Horizontal zone The area of 3 single trian‐
gles
The area of 4 single trian‐
gles
For more information on the recommended cookware dimensions, refer to "Induction
cooking surface" in "Daily use".
12. ENERGY EFFICIENCY
12.1 Energy saving
You can save energy during everyday
cooking if you follow below hints.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on
the cookware.
