4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Water supply
1)
Cold water
Maximum Load Cotton 6 kg
Spin Speed Maximum spin speed 1151 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking and positioning
1.
2.
www.aeg.com8
