The inlet hose
1. Remove the inlet hose from inside the drum.
2. To connect the water inlet hose towards the
proper direction and with the proper inclination,
check the position of the water tap before
connecting it to the back of the appliance.
Make sure the hose is nor kinked,
squashed but neither tensed.
3. Connect the hose to the back of the appliance.
Do not turn the inlet hose downwards, but turn it
left or right depending on the position of your
water tap.
4. Loosen the ring nut to fix it in the correct
position.
5. Connect the water inlet hose to the cold water
tap with 3/4 thread.
WARNING!
The inlet water shall not exceed 25 °C.
WARNING!
Make sure that there are no leaks from the
couplings.
Use the hose supplied with appliance.
Do not use an extension hose if the inlet hose is too short. Contact the Authorised Service
Centre for an inlet hose replacement.
ENGLISH 13
