Water drainage
The drain hose can be connected:
To a stand pipe with vent-hole
Directly into a drain pipe at a height of not less
than 60 cm (23.6”) and not more than 100 cm
(39.3”).
The end of the drain hose must always be
ventilated , i.e. the inner diameter of the drain pipe
(min. 40 mm - min. 1.6”) must be larger than the
external diameter of the drain hose.
To a sink spigot
Put the drain hose in the spigot and tighten it with
the supplied cable tie L.
Make sure that the drain hose makes a loop to
prevent particles going into the appliance from the
sink.
To a wall-pipe
Directly to a built-in drain pipe in the room wall
and tighten it with the supplied cable tie L.
You can extend the drain hose to maximum 400 cm. Contact the service centre for the
other drain hose and the extension.
14 ENGLISH
