AEG LE6F3820SX - Control Panel

4. CONTROL PANEL
4.1 Control panel description
Temp
Spin
Liquid
De
t
ergent
Prew
a
s
h
E
xtra
R
i
nse
Delay
Start
Cottons
Cottons
Synthetics
Delicates
O
S
t
ar
t
/Pause
T
i m e P
r o
Dark clothes
Mix 20°
Wool
Rinse
Drain
Spin
Easy Iron
Jeans
Quick 20´
1 32 54 8 9 1076
1
Programme knob
2
Temperature button (Temp)
3
Spin reduction button (Spin)
4
Display
5
TimePro buttons
(TimePro)
6
Prewash Button (Prewash)
7
Extra rinse button (Extra Rinse)
8
Start/Pause button (Start/Pause)
9
Delay start button (Delay Start)
10
Liquid Detergent button (Liquid
Detergent)
4.2 Display
A B C D
E
FG
A. The Temperature area:
: Temperature indicator
: Cold water indicator
B. : TimePro indicator
C. The time area:
•
: The programme duration
• : The delay start
• : The alarm codes
• : The message of error
• : Programme is completed.
D. : The indicator of the child lock
E. Washing indicators:
• : The washing phase
•
: The rinses phase
ENGLISH 7
