4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2100 W
10 A
50 Hz
Level of protection against ingress of solid particles and moisture ensured
by the protective cover, except where the low voltage equipment has no
protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply
1)
Cold water
Maximum Load Cotton 6 kg
Spin Speed Maximum spin speed 1251 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking and positioning
1.
2.
8 ENGLISH
