35 ENGLISH
Step Action
3 Install the tap.
Install the tap (B) according to the instructions supplied with the
tap (see image 6).
4 Optional: install the filter.
If you need a filter, install the filter (E) according to the instructions
supplied with the filter (see image 7).
When you install the flow meter, mount the flow meter (42) to the
filter according to the instructions supplied with the filter.
5 Attach the t-piece.
Attach the t-piece (14) to the cold water supply and place the seal
(13) in between (see image 8).
6
Mount the pressure safety valve.
If you install the solo configuration:
Attach the pressure safety valve (C) to the bracket (15) with the tie
wrap (24) according to the instructions supplied with the pressure
safety valve.
Place the pressure safety valve (C) with the discharge connection
(20) on the siphon (see image 9).
Mount the bracket (15) with the four screws (25) to the wall of the
kitchen cabinet (see image 10).
If you install the combi configuration:
Mount the pressure safety valve (C) to the mixing valve (D) and
place the adapter (19) and seal (32) in between (see image 11).
Attach the pressure safety valve (C) to the bracket (15) with the tie
wrap (24) according to the instructions supplied with the pressure
safety valve.
Place the pressure safety valve (C) with the discharge connection
(20) on the siphon (see image 12).
Mount the bracket (15) with the four screws (25) to kitchen cabinet
wall (see image 10).
7 Attach the discharge connection.
Attach the discharge connection (20) to the siphon using the screw
funnel (21) (see image 13).
