42 www.aeg.com
Problem Cause Solution
Flow rate too high Too much pressure • Close the valve of the
pressure safety valve (23)
or the cold water supply
valve.
• Place a pressure
reducing valve
Water drips from
the discharge pipe
of the pressure-
relief device
• Do not do anything. This
is normal.
8. TECHNICAL INFORMATION
8.1 Important other technical information
• Refer to the separate manuals supplied with the other components for other
relevant technical information.
8.2 General data
Name AEG ProSource
Ambient temperature 4~38 °C
Humidity range 25~85% relative humidity (RH)
Maximum operation height 2000 m
Protection grade IPX4
8.3 Electrical data
4 litre 8 litre
Connection Earthed AC wall socket
Voltage supply 230 V AC; 50 Hz
Max. power consumption 2200 W
Standby power loss (in ON position) 15 W 20 W
Standby power loss (in OFF position) 0.4 W 0.4 W
