AEG RTB411E1AW - 3.7 Installation of a door handle; OPERATION; 4.1 Control panel

5. Fit the freezer compartment door and
close them.
6. Fix the installation button to the door
lower bearing. Press the installation
button until there is no gap between it
and cavity, then fix the screw.
7. Take out hole covers from a bag and
put them in the holes left after the
door hinge.
3.7 Installation of a door
handle
If there is a door handle separately
provided in a bag, you can install it as
follows:
1. Remove the screws from the holes
on the side of the door. Keep or
install the screw covers on the side
with a door hinge.
2. Match the handle holes with the
holes in the door and screw the
handle with screws previously
removed.
4. OPERATION
4.1 Control panel
3sec
468 2
°C
1 2
3
1 2
3
1. Temperature indicator 2. Super Freeze indicator
ENGLISH 31
