7.1 Replacing the lamp
1.
Disconnect the mains plug from the
mains socket.
2.
Remove the screw from the lamp
cover.
3.
Remove the lamp cover (refer to the
illustration).
4.
Replace the used lamp with a new
lamp of the same power and specifi-
cally designed for household appli-
ances. (the maximum power is
shown on the lamp cover).
5.
Install the lamp cover.
6.
Tighten the screw to the lamp cover.
7.
Connect the mains plug to the mains
socket.
8.
Open the door. Make sure that the
lamp comes on.
7.2 Closing the door
1.
Clean the door gaskets.
2.
If necessary, adjust the door. Refer
to "Installation".
3.
If necessary, replace the defective
door gaskets. Contact the Service
Center.
8. TECHNICAL DATA
Dimension
Height 850 mm
Width 595 mm
Depth 635 mm
Rising Time 12 h
Voltage 230 V
Frequency 50 Hz
The technical information are situated in
the rating plate on the internal left side
of the appliance and in the energy label.
