AEG SFE712FAAS - Page 28

3.1 Dimensions
B
A
H1
W1
D1
W2
D2
W3
D3
90°
Overall dimensions ¹
H1 mm 1218
W1* mm 548
D1 mm 549
¹ the height, width and depth of the
appliance without the handle
* including the width of the bottom hinges
(8 mm)
Space required in use ²
H2 (A+B) mm 1261
W2* mm 548
D2 mm 551
A mm 1225
Space required in use ²
B mm 36
² the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air
* including the width of the bottom hinges
(8 mm)
Overall space required in use ³
H3 (A+B) mm 1261
W3* mm 548
D3 mm 1071
³ the height, width and depth of the
appliance including the handle, plus the
