RIGHT AND BOTTOM SIDES
16
15
14
13
12
CTIA Audio Jack
Combined microphone and speaker
connector
USB 2.0 Port
MicroUSB Interface
For charging only. It is the secondary charging point.
Suggested primary charging point is:
9 (Docking Connector)
MicroSDXC Card Slot
Stereo Speakers (on the sides)
11
9
10
Securing Kensington Locks
Docking Connector
Charging Pads
