3) [Connect to a Power Source] by connecting the DC Short Connector (3)
to a proper DC power supply with an output of 12V to 24V.
Section 4: CLEANING AND MAINTENANCE
Periodically clean the water pump to prevent blockage.
! Caution ! Handle with care to prevent the impeller from falling out and
breaking while detaching the unit. Disconnect Water Pump from Power
before cleaning.
1) Pull the filter housing apart from the pump while squeezing the sides.
2) Press on the bottom board while sliding it in the direction of the arrow.
3) Turn the impeller cover counter-clockwise and then carefully pull it out.
Impeller maybe attached to the cover or stay inside the pump. Be
aware of the white washers may fall out.
4) Separate the impeller from the water pump or detach it from the
impeller cover.
5) Wash every part including the inside of motor chamber and clean out
the debris
6) Assemble the pump in reverse sequence then put water pump back
under water, connect power to start running
Section 5: TROUBLE-SHOOTING
* Pump stopped running?
1) Check power source: if connected to a Solar Panel, make sure it is
fully exposed to sunlight and is not covered in shade or dirt.
Solar cells are connected in series, any shadow or tiny dirt on one
cell could significantly compromise the power output.
2) Check for blockage: clean the pump as described in Section 4:
CLEANING AND MAINTENANCE.
*Pump is running, but there’s no water going through?
1) Check for blockage: clean the nozzle tubes, water pump outlet,
and filter to remove any debris.
Section 6: TECHNICAL DATA AND PUMP CURVE
**If this product is defective or damaged upon delivery, please contact our
customer service by email support@aeoselect.com or
call 909-698-8199 for help. Thank you!
Operating voltage DC 12V-24V
Maximum pump head (Hmax)
Maximum flow rate (Qmax)
196G/H@24V
Dimensions 4.17 x 1.85 x 1.97 inches
Net weight 0.99 lbs.
Cable length 16.4 ft
