CARATTERISTICHE
•
FEATURES
DIMENSIONI • DIMENSIONS (mm)
65
32
= =
7
R 3,5
10,5
65
218,2 466
51,2
1750
1120
1120
1347
760 790
1390
Ø 14
30
1
2
Mod. AN 11 - 117 - 16 - 167 - AN-H 11 - 16
Mod.
Entrata acqua Uscita acqua Tipo attacchi
Water inlet Water outlet Water connections
AN 11 - 16
❶ ❷
maschio • male
AN 117 - 167
❶ ❷
maschio • male
AN-H 11 - 16
❷ ❶
maschio • male
32
130
76
A
L
A
R
M
PANNELLO COMANDI REMOTO • REMOTE CONTROL PANEL
