23
CC
CC
AA
AA
RR
RR
AA
AA
TT
TT
TT
TT
EE
EE
RR
RR
II
II
SS
SS
TT
TT
II
II
CC
CC
HH
HH
EE
EE
FF
FF
EE
EE
AA
AA
TT
TT
UU
UU
RR
RR
EE
EE
SS
SS
0
5
10
15
20
mm C.A. 25
0
25
50
75
100
125
150
175
200
225 Pa
500 550 600 650 700 750 800 rpm
A
B
C
D
E
9 10 11 12 13 rps
Al di sopra di 680 rpm sostituire la puleggia ventilato-
re con una di diametro primitivo Ø 210 B.
Per ottenere i valori delle curve tratteggiate sostituire
il motore di serie con uno da 3 HP.
Over 680 rpm replace the fixed pulley with one
having pitch dia. Ø 210 B.
To obtain the values shown by the dotted lines repla-
ce the standard motor with a 3 HP motor.
Portata aria • Air flow
m
3
/h m
3
/s
A 5400 1,5
B 6100 1,69
C 6800 1,89
D 7500 2,08
E 8200 2,28
TAV 13 CARATTERISTICHE DI VENTILAZIONE UNITÀ INTERNA AS ASH 10
AS ASH 10 INDOOR UNIT FAN PERFORMANCES
0
2,5
5
7,5
10
12,5
15
17,5
20
22,5
25
mm C.A. 27,5
0
25
50
75
100
125
150
175
200
225
250 Pa
500 550 600 650 700 750 800 850 rpm
A
B
C
D
E
9 10 11 12 13 14 rps
Al di sopra di 680 rpm sostituire la puleggia
ventilatore con una di diametro primitivo Ø
210 / 2 B.
Per ottenere i valori delle curve tratteggiate
sostituire il motore di serie con uno da 4 HP.
Over 680 rpm replace the fixed pulley with
one having pitch dia. Ø 210 / 2 B.
To obtain the values shown by the dotted
lines replace the standard motor with a 4 HP
motor .
Portata aria • Air flow
m
3
/h m
3
/s
A 8200 2,28
B 9200 2,55
C 10200 2,83
D 11100 3,08
E 12000 3,33
TAV 14 CARATTERISTICHE DI VENTILAZIONE UNITÀ INTERNA AS ASH 15
AS ASH 15 INDOOR UNIT FAN PERFORMANCES
