25
IFCLITY1106 - 5773010_01
COOLING CAPACITY - FCLI 122
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 8836 7135 8797 8118 8836 8836 9112 9112 9970 9970 10404 10404
17 11401 7099 11378 8101 11355 9089 11332 10073 11298 11049 11309 11309
19 14173 7041 14139 8046 14105 9041 14070 10030 14036 11004 14013 11492
21 17106 7970 17060 8968 17014 9955 16968 10940 16957 11433
23 20245 8867 20222 9877 20153 10857 20130 11351
5
15 7623 6485 7797 7540 8127 8127 8695 8695 9569 9569 10002 10002
17 10336 6543 10313 7541 10278 8524 10324 9532 10439 10439 10553 10553
19 13142 6512 13119 7519 13096 8516 13073 9510 13051 10487 13005 10965
21 16121 7468 16075 8464 16052 9460 16018 10449 16006 10941
23 19305 8393 19260 9387 19214 10377 19191 10869
7
15 6111 5649 6678 6678 7300 7300 8143 8143 9057 9057 9514 9514
17 8789 5768 8773 6762 8915 7802 9199 8888 9577 9577 9829 9829
19 11905 5901 11882 6903 11859 7895 11813 8873 11836 9868 11859 10372
21 14975 6905 14929 7896 14906 8889 14884 9880 14861 10363
23 18206 7857 18183 8859 18137 9847 18114 10337
7
3
15 6859 6093 6954 6954 7332 7332 8206 8206 9073 9073 9498 9498
17 9443 6092 9419 7085 9388 8067 9380 9049 9545 9545 9671 9671
19 12203 6048 12180 7051 12157 8046 12111 9018 12100 9999 12065 10476
21 15136 6987 15090 7979 12111 9018 15021 9949 15010 10440
23 18274 7897 18252 8899 18206 9886 18183 10376
5
15 5662 5429 6158 6158 6875 6875 7781 7781 8671 8671 9104 9104
17 8206 5484 8175 6467 8285 7492 8521 8521 8884 8884 9183 9183
19 11069 5500 11046 6499 11034 7493
11000 8470
10989 9450 11011 9955
21 14059 6471 14036 7471 14013 8460 13967 9434 13956 9923
23 17243 7406 17221 8404 17175 9388 17152 9877
7
15 4410 4410 5308 5308 6269 6269 7222 7222 8143 8143 8600 8600
17 6190 4527 6552 5653 7025 6796 7568 7568 8206 8206 8616 8616
19 9514 4777 9514 5781 9482 6758 9577 7786 9797 8843 9923 9374
21 12753 5868 12730 6862 12707 7845 12684 8827 12684 9320
23 16029 6850 16006 7845 15960 8824 15960 9322
9
3
15 4993 4993 5536 5536 6422 6422 7300 7300 8167 8167 8600 8600
17 7340 5069 7308 6048 7379 7053 7608 7608 8190 8190 8616 8616
19 10118 5056 10095 6051 10072 7035 10041 8008 10018 8982 10033 9480
21 13039 6001 13005 6990 12982 7975 12959 8958 12936 9436
23 16189 6928 16155 7917 16121 8902 16098 9388
5
15 4103 4103 5009 5009 5946 5946 6867 6867 7765 7765 8206 8206
17 5765 4333 6017 5403 6426 6426 6985 6985 7781 7781 8222 8222
19 8805 4460 8789 5450 8773 6435 8821 7437 8994 8466 9120 8990
21 11836 5459 11813 6450 11790 7430 11768 8407 11756 8890
23 15044 6416 15021 7405 14975 8382 14975 8879
7
15 3103 3103 4276 4276 5308 5308 6285 6285 7230 7230 7686 7686
17 3733 3336 4631 4623 5465 5465 6300 6300 7245 7245 7702 7702
19 6710 3550 6757 4554 7025 5630 7434 6751 7923 7869 8190 8190
21 10278 4785 10255 5767 10255 6752 10278 7745 10347 8261
23 13669 5825 13646 6810 13623 7792 13600 8274
COOLING CAPACITY CORRECTION FACTORS
FCLI 122
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 1750 1 1
Speed V3 1350 0.81 0.81
Speed V2 1100 0.68 0.68
Speed V1 750 0.49 0.48
