37
IFCLITY1106 - 5773010_01
FEL10
For GLLI10 and GLLI10N grille units.
Electrostatically pre-charged air filter, regenerated with
class-2 fire resistance (UL 900).
Supplied in a sealed package which should only be opened
at the time of use.
The electrostatically pre-charged filter combines the normal
mechanical filtering of the air that passes through the filter,
with an electrostatic attraction of powder that increases its
filtering considerably.
The electrostatic filter charge runs down two years after
the opening of the box; after this period it behaves like a
normal filter.
Frequent cleaning, removal (with a vacuum) of the dust that
has built up, and the use of water and detergents consider-
ably speeds up the deterioration of the electrostatic charge.
GLLI 10
GLLI 20
The GLLI includes the electric box, with bayonet coupling
to the connector bound to the unit's load-bearing
structure.
The GLLI needs to be interfaced with an external control
panel (not included) ) with thermostat and ventilation
speed control, with a 0-10V output.
FEL10 ELECTROSTATICALLY PRE-CHARGED AIR FILTER
GLLI10 - GLLI20 INTAKE AND DELIVERY GRILLE UNIT
ACCESSORIES
GLLI10 (600x600)
GLLI20 (840x840)
Suction and delivery grille unit
The grille is part of the GLLI range grille unit (obligatory
accessory).
The form and opening of the suction louvres were developed in
order to have the best possible distribution of the air, both when
functioning in winter as well as in summer.
Suction occurs through the central grille, and delivery through
the manually adjustable, perimetric slots. In plastic, colour RAL
9010, it contains the air filter that can be easily removed for
cleaning.
