13
Tw [°C] ∆t Ta b.u. [°C] Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
21°C Ta b.s. 23°C Ta b.s. 25°C Ta b.s. 27°C Ta b.s. 29°C Ta b.s. 31°C Ta b.s.
13 3 15
17 540 501 745 691 1049 973 1317 1221 1572 1458 1818 1686
19 668 443 820 696 1071 977 1321 1225 1576 1462 1822 1690
21 1654 752 1632 973 1667 1206 1757 1449 1891 1691
23 2539 1000 2522 1216 2509 1440 2496 1662
5 15
17
19 434 342 601 509 792 735 984 913 1179 1093 1472 1365
21 770 457 868 688 1008 905 1181 1095 1477 1370
23 1356 615 1364 842 1492 1083 1710 1371
7 15
17
19
21 511 359 676 586 846 785 1036 961 1228 1139
23 876 470 971 701 1101 924 1252 1133
15 3 15
17
19 365 313 545 505 771 715 1066 989 1330 1233 1580 1466
21 704 436 915 717 1123 985 1332 1235 1585 1470
23 1822 761 1814 985 1814 1210 1878 1446
5 15
17
19
21 442 334 606 551 792 735 984 913 1196 1109
23 794 445 889 675 1023 895 1213 1118
7 15
17
19
21
23 521 350 684 577 853 781 1036 961
Cooling capacities are referred to high speed.
To obtain values for other speed, multiply the values read by following factors:
MOD. FCW 21
Medium speed
total capacity
0,89
sensible capacity
0,87
Minimum speed
total capacity
0,76
sensible capacity
0,71
Water flow rate as at maximum ventilation speed;
Tw [°C] = Inlet water temperature
Ta w.b. [°C] = Inlet wet bulbe air temperature
Ta b.s. [°C] = Dry bulbe air temperature
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NOTE: Values of capacity in bold face refer to nominal value.
Values of sensible capacity higher than values of total capacity mean that cooling is without dehumidification in this case
consider only the values of sensible capacity.
