Cooling capacities are referred to high speed.
To obtain values for other speed, multiply the values read by following factors:
MOD. FCW 31
Medium speed
total capacity
0,81
sensible capacity
0,79
Minimum speed
total capacity
0,68
sensible capacity
0,65
Water flow rate as at maximum ventilation speed;
Tw [°C] ∆t Ta b.u. [°C] Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
21°C Ta b.s. 23°C Ta b.s. 25°C Ta b.s. 27°C Ta b.s. 29°C Ta b.s. 31°C Ta b.s.
13 3 15
17 768 695 1058 958 1491 1350 1871 1694 2234 2022 2583 2339
19 949 614 1166 966 1522 1355 1878 1700 2240 2028 2589 2344
21 2350 1043 2319 1349 2368 1674 2497 2009 2688 2346
23 3608 1387 3584 1687 3565 1998 3547 2305
5 15
17
19 617 474 854 706 1126 1019 1399 1266 1675 1516 2092 1894
21 1095 634 1233 954 1433 1256 1678 1519 2098 1900
23 1927 854 1939 1167 2121 1503 2430 1902
7 15
17
19
21 726 498 960 813 1202 1089 1473 1333 1746 1580
23 1245 651 1380 973 1565 1282 1779 1572
15 3 15
17
19 518 434 774 701 1095 991 1515 1372 1890 1711 2246 2033
21 1000 605 1301 994 1595 1366 1893 1714 2252 2039
23 2589 1056 2577 1366 2577 1678 2669 2006
5 15
17
19
21 629 464 862 765 1126 1019 1399 1266 1699 1539
23 1129 617 1264 937 1454 1241 1724 1551
7 15
17
19
21
23 740 486 972 800 1212 1084 1473 1333
Tw [°C] = Inlet water temperature
Ta w.b. [°C] = Inlet wet bulbe air temperature
Ta b.s. [°C] = Dry bulbe air temperature
Pc [W] = Total cooling capacity
Ps [W] = Sensible cooling capacity
NOTE: Values of capacity in bold face refer to nominal value.
Values of sensible capacity higher than values of total capacity mean that cooling is without dehumidification in this case
consider only the values of sensible capacity.
