1508 - 5138800_00
&tt/d,D/ZKWZK^^KZKEdZK>>Z
Ͳhy/>/ZzDZ'Ez^t/d,ΗhyΗ
ϮͲFAN SPEED
ϯͲKWZd/E'DK
Dehumidification
Cooling
Heating
Fan only
ϰͲd/DZ
The icon shows the timer is active
&tt/d,D/ZKWZK^^KZKEdZK>>ZͲ&ZKEdWE>/^W>z
When the fan coil unit is powered up it emits a beep. When the fan coil unit is powered but not on, all the LEDs are
off.
hy/>/ZzDZ'Ez^t/d,;hyͿ
When the remote control is not available (not functioning or
with flat batteries) or the wired control panel is not function-
ing, the auxiliary emergency switch can be used to activate
the fan coil unit.
The switch is not sized for continuous use. Repair the remote
control or the wired control panel as soon as possible.
^ƚĂƌƚŝŶŐĂŶĚ ŽƉĞƌĂƚŝŶŐǁŝƚŚƚŚĞĂƵdžŝůŝĂƌLJĞŵĞƌŐĞŶĐLJƐǁŝƚĐŚ
;hyͿ
- First press: Cooling with set point 25°C, automatic ventila-
tion, swinging blades
- Second press: Heating with set point 22°C, automatic venti-
lation, swinging blades
- Third press: Fan coil unit turned off
tĂƚĞƌƚĞŵƉĞƌĂƚƵƌĞĚŝƐƉůĂLJ;ŽŶ ƚŚĞĨƌŽŶƚƉĂŶĞůĚŝƐƉůĂLJͿǁŝƚŚ
ƚŚĞĞŵĞƌŐĞŶĐLJĂƵdžŝůŝĂƌLJƐǁŝƚĐŚ;hyͿ
- Set the operation mode Cooling
- First press for 5 seconds: the display shows the temperature
of the water in the coil
- Second press for 5 seconds: the display shows the tempera-
ture of the water inlet
- Third press: Fan coil unit turned off
AUX
( On / Off )
ŝƐƉůĂLJ
Temperature Description
Σ
Set temperature
(normal operation)
- Set temperature (flashing)
(during setting)
- Water temperature in battery
(see functions to activate the AUX button)
- Water inlet temperature
(see functions to activate the AUX button)
ƌƌŽƌĐŽĚĞ
ŇĂƐŚŝŶŐ
alternately with
the ambient
temperature
Error ĚĞƐĐƌŝƉƚŝŽŶ
E1 (RM) Ambient air temperature sensor fault
E2
(ID) Water temperature in the coil sensor
fault
E3 (OD) Water inlet temperature sensor fault
E4
(OD) Water inlet temperature is not suitable
mode of operation
E6 ƌƌŽƌĐŽŵŵƵŶŝĐĂƟŶŐǁŝƚŚƚŚĞǁŝƌĞĚƉĂŶĞů
ϭͲdDWZdhZ/^W>zZZKZK^
