Multichiller
Collegamento PCO1
Type of connection bus between multichiller and chiller
PCOE expansion
Multichiller
Chiller
Serial RS485 max. distance 1000 mt
Serial RS485 max. distance 600 mt
Connect a 120 ohm resistance tot
he first and last node (1/4 W)
(included in the kit)
