IVEDITI 1707 - 4880981_01
ACCESSORIES
Intake grid with fixed louvers and subframe, made of steel sheet metal and painted with powders.
B
A
D
E
C
F
26
6
A
B
H
C
E
G
36
6
F
D
[]
GA 22 32 42 62
A 506 737 957 1078
B 214 214 214 244
C 550 781 1001 1122
D 258 258 258 288
E 500 731 951 1072
F 208 208 208 238
Intake grid with fixed louvers complete with filter insertion frame and subframe, made of steel and painted with powders. The filter is
supplied.
[]
GAF 22 32 42 62
A 561 792 1012 1133
B 270 270 270 300
C 605 836 1056 1177
D 314 314 314 314
E 554 785 1005 1126
F 262 262 262 292
G 500 731 851 1072
H 208 208 208 238
Attention
- GAF
Attention
- GA
B
A
60
F
D
E
C
6
48
A B C D E F
457 134 502 178 452 128
688 134 733 178 683 128
908 134 953 178 903 128
1029 134 1074 178 1024 128
Flow grid to diffuse air with thermoplastic adjustable louvers. Complete with subframe.
Attention
- RD
GA IINTAKE GRID
