Clipper
Clipper building instructions
4
No. Component Material No. off Type
1 Deck / jig Obechi 1 Die-cut
2 Keel Plywood 1 Die-cut
3 Bulkhead Plywood 1 Die-cut
4 Bulkhead Plywood 1 Die-cut
5 Bulkhead Plywood 1 Die-cut
6 Bulkhead Plywood 1 Die-cut
7 Bulkhead Plywood 1 Die-cut
8 Bulkhead Plywood 1 Die-cut
9 Keel Plywood 1 Die-cut
10 Keel Plywood 1 Die-cut
11 Bow Plywood 1 Die-cut
12 Bulkhead Plywood 1 Die-cut
13 Corner strip Balsa 2 5 x 5 x 495 mm
14 Mast socket Aluminium 1 7 Ø x 41 mm
15 Reinforcement Mahogany 2 Die-cut
16 Hull side Plywood 2 Die-cut
17 Hull bottom Plywood 1 Die-cut
18 Hull bottom Plywood 1 Die-cut
19 Boatstand Plywood 1 Die-cut
20 Boatstand Plywood 1 Die-cut
21 Boatstand Plywood 2 Die-cut
22 Ballast Metal 1 14.5 Ø x 95 mm
23 Fabric tape Cotton 1 Ready made, 350 mm
24 Rudder Plastic 1 Ready made, shaft M3 x 35 mm
25 Rudder bush Brass 1 4 Ø x 24 mm
26 Washer Brass 1 Bored 3 mm Ø
27 Self-locking nut Metal 2 M3, ready made
28 Steering arm Plastic 1 Ready made
29 Hatch cover Obechi 1 Die-cut
30 Reinforcement Plywood 1 Die-cut
31 Reinforcement Plywood 1 Die-cut
32 Handle Plywood 1 Die-cut
33 Hatch support rail Obechi 2 Die-cut
34 Superstructure floor Mahogany 1 Die-cut
35 Superstructure wall Mahogany 1 Die-cut
36 Superstructure side panel Mahogany 2 Die-cut
37 Superstructure wall Mahogany 1 Die-cut
38 Superstructure roof Mahogany 1 Die-cut
39 Jib Fabric 1 Die-cut
40 Mainsail Fabric 1 Die-cut
41 Sail tabling Fabric 1 Die-cut
42 Sail tabling Fabric 1 Die-cut
43 Sail tabling Fabric 1 Die-cut
44 Sail tabling Fabric 1 Die-cut
45 Sail tabling Fabric 1 Die-cut
46 Sail tabling Fabric 1 Die-cut
47 Sail tabling Fabric 1 Die-cut
48 Ring Stainless steel 16 Ready made
49 Oval ring Stainless steel 7 Ready made
50 Mast Aluminium 1 6 Ø x 510 mm
51 Spring-ring Stainless steel 7 Ready made
52 Main boom Aluminium 1 6 Ø x 250 mm
53 Jib boom Aluminium 1 6 Ø x 160 mm
54 Screw Brass 1 M2 x 12 mm
55 Self-locking nut Brass 1 M2
56 Sliding clamp Plastic 2 Ready made
57 Cord 1000 mm
58 Ring-screw Brass 3 Ready made
59 Servo plate Plywood 1 Die-cut
60 Rudder pushrod Steel 1 Ready made
61 Sanding block Plywood 1 Pre-cut
62 Glasspaper 1 Pre-cut
