Mount the metal brackets to the
double DIN head unit.
The position of the copper
coloured holder can be adjusted
to your needs for perfect t.
(see sample)
(sample photo) (sample photo)
1. Prepare the Double DIN
head unit.
Installation Manual Double DIN Kit 381230-00
2. Remove the OEM head unit
3. Place Metal Frame into
the dashboard.
Connect all required circuit points
and push the double DIN head
unit in the metal frame until it
snaps in.
Place the trim frame.
All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
