aevit VIC 2.0 User Manual

VIC 2.0 INSTALL MANUAL
      
           
      
           
 
 
 
     
   
                        
32B
VIC 2.0 INSTALLATION
INSTALLATION STEP 4B - SINGLE SPEAKER
The following diagram shows how to wiring the VIC 2.0 if only one OEM speaker is being used.
PIN #
HARNESS WIRE
COLOR
FUNCTION
5 WHITE + SPEAKER (SS)
8 BLUE - SPEAKER (SS)
PIN #
HARNESS WIRE
COLOR
FUNCTION
1 RED + SPEAKER (RS)
4 GREEN - SPEAKER (RS)

aevit VIC 2.0 Specifications

General

Brand	aevit
Model	VIC 2.0
Category	Control Unit
Language	English
