8
Handlebars (1) Your Breeze is delivered to you with right-hand
controls.
(Left-hands controls can be setup by your
dealer).
Serial No. (1.2) Serial Number and Manufacturer’s data are fixed
near the Charging Fuse (2.1C).
Operating lever (1.3) Use to control the Breeze speed. Standard is
right hand (optional left hand).
Charging Socket (1.4) The socket is used to connect the charger plug
for batteries charging. Right hand side of the
Handlebar.
Handlebars Adjusting Lever
(1.5)
The Handlebar of the Breeze is adjustable
Forward and Reverse by releasing the Adjusting
Lever.
Buzzer (1.6)
Front Basket (1.7)
For carrying parcels and personal effects.
Maximum load 5 kg (11 lbs).
Headlight and Blinkers (1.8) (A) Road light for dark hours
(B) Blink light for turnings mark
Electric Button to release the
Electromagnetic Brake (1.9)
Located on the Handlebar of the Breeze, the
Electromagnetic Brake Release button allows
free movement of the Breeze.
To engage just push the button.
To release the brake just leave the button.
Battery Cover (2) Protect the power unit and electronics.
Fuses (2.1A, 2.1C) 2.1A -Main fuses 70A – Semi Automatic
2.2C –Supply fuse -3A – Semi Automatic
(at the electronics box side)
2.1C – Charge fuse 15A–Semi Automatic
Manual Release of
electromagnetic brake (2.2)
The lever is at the rear area of the Breeze in the
front of the right wheel. Manual release lever
allow you to push or pull the Breeze manually.
Push / Pull the lever as shown in the
label:
Release, Engaged. When
the lever is in released position the Breeze can
not be operated.
Note: Do not release the lever when the Breeze
is on slope.
Seat (3) The Breeze Seat is equipped with folding
armrests (3.4) to allow convenient access to the
Seat. The Seat itself can be rotated to allow
easy access.
