9
Seat Forward / Reverse Lever
(3.1)
The Lever is used to change the seat position
Forward and Reverse , to fit the driver mostly.
Seat Rotation Lever (3.2) The Lever is used to swivel the Seat 45 and 90
degrees in either direction, to ease the driver's
access to the Seat.
Seat Height adjust The Seat Height can be Adjusted Up / Down to
fit the user Height. This adjustment can be made
by a technician.
For adjusting the seat height , You need to
remove the seat and the batteries cover , and
than remove the screw that secure the seat pin
and to reassemble it at another hole as desired,
than re-secure the screw and nut.
Rear Basket (3.3)
For carrying parcels and personal effects.
Maximum load 20 kg (44 lbs).
Hand Rest (3.4) Use for comfort entrance, Folded.
Floor (4) Carpet covered. Possible to remove for
cleaning.
Figure 3
To Next Page
