5
11
Door latch-When the door is closed it
will automatically shut off. If the door is
opened while the oven is operating, the
magnetron will automatically shut off.
22
Door seal-The door seal maintains the
microwave within the oven cavity and
prevents microwave leakage.
33
Oven cavity
44
Spatter shield-Protects the microwave
outlet from splashes of cooking foods.
55
Safety interlock system-Prevents the
oven from operating while the door is
opened.
66
Control Panel
77
Glass cooking tray-Made of special
heat resistant glass. The tray must
always be in proper position before
operating.
Do not cook food directly on the tray.
88
Roller guide-Supports the glass
cooking tray.
99
Door screen-Allows viewing of food.
The screen is designed so that light can
pass through, but not the microwaves.
FEATURES DIAGRAM
