AFX ROLLER-LIGHT2 - DMX Channel Table

© Copyright LOTRONIC 2015 ROLLER-LIGHT2 Page 5
DMX CHANNEL TABLE
12 DMX channels mode
12 Channel Mode Function value
1 MOTOR 1
0---127， 0°-------360°，
128---191 Clockwise rotation from fast to slow
192---255 Counterclockwise rotation from slow to fast
2 MOTOR 2
0---127， 0°-------360°，
128---191 Clockwise rotation from fast to slow
192---255 Counterclockwise rotation from slow to fast
3 DIMMER 0-255 0-100%
4 STROBE
0---15 ON，
16---131 FROM SLOW TO FAST，
132—139 ON，
140—181 FAST OFF SLOW ON,
182—189 ON，
190—231 SLOW OFF FAST ON，
232—239 ON，
240---247 Random strobe,
248—255 ON
5 LED1 RED DIMMER 0—255 0-100%
6 LED1 GREEN DIMMER 0—255 0-100%
7 LED1 BLUE DIMMER 0—255 0-100%
8 LED1 WHITE DIMMER 0—255 0-100%
9 LED2 RED DIMMER 0—255 0-100%
10 LED2 GREEN DIMMER 0—255 0-100%
11 LED2 BLUE DIMMER 0—255 0-100%
12 LED2 WHITE DIMMER 0—255 0-100%
