1.
Fig 22 shows the required clearance from
the edge of the cleat (on the main belt) to
the edge of the side skirt, A = 10
2.
The rubber side skirts must be in contact
with the flat of the main
this is not achieved sand and stones will
collect under the belt resulting in a stretched
or torn belt.
3.
Fig 23 shows an incorrectly fitted belt, either
the side skirts are too long or the cleats are
too long on the discharge belt clea
result –
sand, stones and material will build
up on the head/tail rollers resulting in a
slack belt!
4.
If the situation in Fig 23 occurs, the belt
cleats can be trimmed Fig 24
5.
Fig 24 shows the trimming process. Use a
sharp knife and some lubricati
circumstances should the flat of the
discharge belt be cut. Cut down line (A)
when the cleat position is over the roller,
thus giving you support.
6.
Fig 25 shows completing the trimming
process.
7.
Trimming the cleats is a delicate process,
and
must not be rushed; any damage to the
flat cover of the flat will void any warranty.
8.
If trimming is to be carried out , every cleat
must be trimmed to the same specification
on both edges, Failure to do this will result
in a unbalanced belt
Fig 22 shows the required clearance from
the edge of the cleat (on the main belt) to
the edge of the side skirt, A = 10
-15mm
The rubber side skirts must be in contact
with the flat of the main
discharge belt. If
this is not achieved sand and stones will
collect under the belt resulting in a stretched
Fig 23 shows an incorrectly fitted belt, either
the side skirts are too long or the cleats are
too long on the discharge belt clea
ts. The
sand, stones and material will build
up on the head/tail rollers resulting in a
If the situation in Fig 23 occurs, the belt
cleats can be trimmed Fig 24
Fig 24 shows the trimming process. Use a
sharp knife and some lubricati
on. Under no
circumstances should the flat of the
discharge belt be cut. Cut down line (A)
when the cleat position is over the roller,
thus giving you support.
Fig 25 shows completing the trimming
Trimming the cleats is a delicate process,
must not be rushed; any damage to the
flat cover of the flat will void any warranty.
If trimming is to be carried out , every cleat
must be trimmed to the same specification
on both edges, Failure to do this will result
