Assembly Instructions
Step 7:
Step 8:
Page 11 of 23
Attach a spring to the opposite of V-ring.
IMPORTANT: You will now need to use
the spring tool (part F) to attach the
spring to the frame.
Hook the spring tool onto end of spring,
and pull until the spring can be slotted
into the spring slot on the top of the
frame.
IMPORTANT: Ensure the spring is fully
inserted into the slot on the frame.
Continue to attach springs in the same sequence as above: in the middle of each
section, making sure the next spring is attached on the opposite side to even out
the tension.
Important: The stitched bed is designed like elastic to be bouncy, which means that
during construction, it may look like it won’t fit. Please note that it will stretch to the
correc
t size when attaching the springs, this may take some force.
The stitched bed is now fitted, and you have completed step 8.
