Assembly Instructions
Step 1:
Step 2:
Page 8 of 23
You will need the following parts to
complete section 1:
6 x Top tube with T-connector - Part A
6 x Straight leg - Part B
6 x Plastic foot cap - Part C
6 x Self-tapping screw - Part J
First we will complete one of the
sections of the trampoline frame.
Slot the narrow end of the top tube
with T-connector into another top
tube with T-connector.
2 Spring Holes on Top
4 Spring Holes on Bottom
