Assembly Instructions
Step 15:
Page 15 of 23
As soon as the poles are bent enough,
insert the connectors into the socket on
the other pole (1).
Push the pin inwards (2) and fully insert
the connector.
Ensure the pin is protruding through the
slot in the socket.
Use the strap on the enclosure net to
cover the exposed pole connections.
Step 16:
You will need the following parts
6 x Top enclosure tubes - Part H
6 x Bottom enclosure tubes - Part I
6 x Self-tapping screw - Part J
You will also need a cross-head
screwdriver (not supplied)
