Assembly Instructions
Step 17:
Step 18:
Page 21 of 27
You will need the following parts to complete
7 x Top enclosure tube - Part I
7 x Bottom enclosure tube - Part J
You will also need a cross-head screwdriver
(not supplied )
Slot, Part J, the bottom enclosure tubes into,
Part I, the top enclosure tubes.
Align the hole on the bottom enclosure
tube with the slot in the top enclosure
tube.
Screw one of the self tapping screws
through the slot in the top enclosure
tube and into the hole in the bottom
enclosure tube using the crosshead
screwdriver.
