Assembly Instructions
Step 19:
Step 20:
Page 22 of 27
Place the round cap, Part N,
onto the top enclosure pole,
Part I.
Slot the bottom of the enclosure
pole into the open T- connector
B tube, Part B. Slot should be
visible through the opening in
the frame pad.
Assemble the six remaining
enclosure tubes using the six
self tapping screws and the
cross-head screwdriver.
