Assembly Instructions
Step 21:
Step 22:
Attach the backboard (P) and rim
with net (Q), tighten with a plastic
nut (V).
The regular part (T) can adjust the
angle.
Now install the basket Game to the curved tube (J), attach the regular part
(T) to the curved tube (J), tighten with two connecting bolts (U) and four small
nuts (Y).
The concave side of regular part (T) is close to the curved tube (J).
Page 18 of 22
