BUTTONS & FEATURES
2
REDIAL/P
WALL MOUNTING
Position the telephone where you want to fix it to the wall. Drill two holes and fix
roundheaded screws, leaving them slightly proud of the surface. Position the
telephone over the screws and slide downwards into place.
MEMORY KEYS
MESSAGE LED
HOLD
RECALL
HANDSFREE
NUMERICAL KEYS
HEADSET PORT
TELEPHONE HANDSET PORT
VOLUME (LO/MID/HI)
LINE
EXT
MESSAGE WAITING SWITCH
HOLES FOR WALL MOUNTING
RING (LO/HI)
RECALL (TBR/ELR)
