Agilent Technologies 81110A - Setting Up a Pulse Signal

36
Getting Started
S
SS
Se
ee
ett
tttt
tti
ii
in
nn
ng
g g
g U
UU
Up a
p a p a
p a C
CC
Cl
ll
loc
ococ
ock
k k
k S
SS
Si
ii
ig
gg
gna
nana
nal
ll
l
P
PP
Pr
rr
ro
oo
og
gg
gr
rr
ra
aa
am
mm
mm
mm
mi
ii
ing
ng ng
ng
E
EE
Ex
xx
xa
aa
am
mm
mp
pp
pl
ll
le
ee
e
If you want to include this clock signal in your GP-IB program, use the
following command lines. The comment lines starting with a # are not
required.
# Reset the instrument to start from a defined, default status.
*RST
# Switch off the automatic display update to increase programming
# speed.
:DISPlay OFF
# Internal PLL has to be set as period source.
:ARM:SOURce INT2
# Set the frequency to 50 MHz, the duty cycle to 50% and the leading
# and trailing edge to 3 ns. Settings are to program for output 1.
:FREQuency 50MHZ
:PULSe:DCYCle1 50
:PULSe:TRANsition1 3NS
# For example, the same settings for the optional second channel will
# look like as follows:
:PULSe:DCYCle2 50
:PULSe:TRANsition2 3NS
# Set the high level to 2.5 Volts, the low level to 0.0 Volts.
:VOLTage1:HIGH 2.5V
:VOLTage1:LOW 0V
# Enable the output 1 and the complement output 1 (Agilent 81110A
# with Agilent 81112A 3.8V/330 MHz output channel installed, only).
:OUTPut1 ON
:OUTPut1:COMPlement ON
