External Width Mode
In external width mode, the pulse width is determined by an external
signal

The pulse width is determined by an external signal:

MAN key: Pressing the key generates a leading edge, releasing the
key generates a trailing edge.
EXT-IN: A rising-edge at the EXT INPUT generates a leading edge,
a falling edge at the EXT INPUT generates a trailing edge.

The threshold and impedance of the EXT INPUT can be selected on
the Trigger-Level screen.

The period, delay, and width of the output pulse are not
programmable in this mode as they are determined by the external
signal.
