89
Using the 81110A/81104A
T
TT
Th
hh
he
e e
e P
PP
Pa
aa
at
tt
tt
tt
te
ee
er
rr
rn
n n
n S
SS
Sc
cc
cr
rr
re
ee
ee
ee
en
nn
n
Update Parameter
Select to update the hardware after each of your changes in the screen or
only on demand.
UPDATE (select U
PD
C
ONT
)
The pattern data at the outputs are updated continuously as you edit
the data on the screen.
NO UPD (select U
PD
O
NCE
)
The pattern data at the outputs are not updated automatically from
the screen. You can therefore modify the data patterns on the screen
without affecting the pattern which is currently being generated at
the Outputs.
Press ENTER to update the pattern once.
Address Parameter
Adjust the address of the bit-editing window to scroll through the data.
The figure in the following section shows the bit-editing window with the
third bit in the pattern selected.
Last Parameter
Adjust the last bit number to set the length of the pattern in the range of
216384.
