Agilent Technologies 8591E User Manual

104 Chapter2
Making Adjustments
15. Frequency Response of the 8590L, 8591C, and 8591E
Table 2-6 Frequency Response Errors
Column 1
Frequency
(MHz)
Column 2
ErrorRelative
to 300 MHz
(dB)
Column 3
Sensor
CAL FACTOR
(GHz)
Column 4
(75 Ω inputs)
System Error
(dB)
Column 5
(75 Ω inputs)
Corrected Error
Relative to
300 MHz (dB)
4 _______________ N/A N/A _______________
41 _______________ 0.03 _______________ _______________
78 _______________ 0.1 _______________ _______________
115 _______________ 0.1 _______________ _______________
152 _______________ 0.1 _______________ _______________
189 _______________ 0.3 _______________ _______________
226 _______________ 0.3 _______________ _______________
263 _______________ 0.3 _______________ _______________
300 _______________ 0.3 _______________ _______________
337 _______________ 0.3 _______________ _______________
374 _______________ 0.3 _______________ _______________
411 _______________ 0.3 _______________ _______________
448 _______________ 0.3 _______________ _______________
485 _______________ 0.3 _______________ _______________
522 _______________ 0.3 _______________ _______________
559 _______________ 1.0 _______________ _______________
596 _______________ 1.0 _______________ _______________
633 _______________ 1.0 _______________ _______________
670 _______________ 1.0 _______________ _______________
707 _______________ 1.0 _______________ _______________
744 _______________ 1.0 _______________ _______________
781 _______________ 1.0 _______________ _______________
818 _______________ 1.0 _______________ _______________
855 _______________ 1.0 _______________ _______________
892 _______________ 1.0 _______________ _______________
