120 Chapter2
Making Adjustments
16. Frequency Response of the 8592L/94L, 8593E/94E/95E/96E, and 8594Q
Frequency Response Errors Band 3
15.210 _____________________ 15.0
15.440 _____________________ 15.0
15.670 _____________________ 16.0
15.900 _____________________ 16.0
16.130 _____________________ 16.0
16.360 _____________________ 16.0
16.590 _____________________ 17.0
16.820 _____________________ 17.0
17.050 _____________________ 17.0
17.280 _____________________ 17.0
17.510 _____________________ 18.0
17.740 _____________________ 18.0
17.970 _____________________ 18.0
18.200 _____________________ 18.0
18.430 _____________________ 18.0
18.660 _____________________ 19.0
18.890 _____________________ 19.0
19.120 _____________________ 19.0
19.350 _____________________ 19.0
Frequency Response Errors Band 4
19.150 _____________________ 19.0
19.300 _____________________ 19.0
19.450 _____________________ 19.0
19.600 _____________________ 20.0
19.750 _____________________ 20.0
19.900 _____________________ 20.0
20.050 _____________________ 20.0
Table 2-8 Frequency Response Errors
Column 1 Frequency
(GHz)
Column 2
Measuring Receiver
Reading (dB)
Column 3
CAL FACTOR
Frequency (GHz)
To Next Page
