Agilent Technologies E4428C Configuration Guide

2
E4428C ESG Analog Signal Generator
Configuring your E4428C analog signal generator
The following steps will guide you through configuring your Agilent Technologies E4428C analog
signal generator with the performance you need.
Step 1 Choose a frequency range (Mandatory)
Ordering # Description Requires Not compatible For more information go to:
www.agilent.com/find/esg
E4428C-503 250 kHz to 3 GHz frequency range 506
E4428C-506 250 kHz to 6 GHz frequency range 503
*(Mechanical attenuator only–Option UNB
performance is included with Option 506)
Step 2 Choose an attenuator
Ordering # Description Requires Not compatible For more information go to:
www.agilent.com/find/esg
E4428C-UNB High output power with mechanical 503 506 Data Sheet: 5989-1992EN
attenuator: Increase the output power
up to 6 dB for higher power applications.
(Option UNB performance is included
with Option 506)
Step 3 Choose accessories or instrument connector configuration
Ordering # Description Requires Not compatible For more information go to:
www.agilent.com/find/esg
E4428C-1EM Moves all front panel connectors to rear panel
E4428C-1CM Rack mount without handle 1CP, 1CN
E4428C-1CP Rack mount kit with handles 1CM, 1CN Catalog: 5980-0450E
E4428C-1CN Front handle kit 1CP, 1CM Catalog: 5980-0450E
Step 4 Choose a warranty and calibration plan
Ordering # Description
R-51B-001-C Standard 1-year Return-to-Agilent warranty and service
R-51B-001-3C 1 year Return-to-Agilent warranty extended to 3 years
R-51B-001-5C 1 year Return-to-Agilent warranty extended to 5 years
R-50C-001-3 Return-to-Agilent Calibration Upfront Suppport Plan 3 year coverage
R-50C-016-3 Return-to-Agilent 17025 Calibration Upfront Support Plan 3 year coverage
R-50C-021-3 Return-to-Agilent Z540 Calibration Upfront Support Plan 3 year coverage
E4428C-UK6 Commercial calibration certificate and test data
