4
E4438C ESG Vector Signal Generator
Configuring your E4438C vector signal generator
The following steps will guide you through configuring your Agilent Technologies E4438C vector
signal generator with the performance you need.
Step 1 Choose a frequency range (Mandatory)
Ordering # Description Requires Not compatible For more information go to:
www.agilent.com/find/esg
E4438C-501 250 kHz to 1 GHz frequency range 502, 503, 504, 506
E4438C-502 250 kHz to 2 GHz frequency range 501, 503, 504, 506
E4438C-503 250 kHz to 3 GHz frequency range 501, 502, 504, 506
E4438C-504 250 kHz to 4 GHz frequency range 501, 502, 503, 506
E4438C-506 250 kHz to 6 GHz frequency range UNJ UNB*, 300, 501,
*(Mechanical attenuator only– 502, 503, 504
Option UNB performance is
included with Option 506)
Step 2 Choose phase noise performance
Ordering # Description Requires Not compatible For more information go to:
www.agilent.com/find/esg
Standard Standard phase noise performance Data Sheet: 5988-4039EN
E4438C-UNJ Enhanced phase noise performance: 300, 1E5 Data Sheet: 5988-4039EN
Up to 20 dB single sideband (SSB)
improvement over standard performance.
(Option 1E5 performance is included)
