Chapter 10 283
Replaceable Parts Lists and Locations
Hardware
Reference
Designator
Description Agilent Part
Number
W1 W1 Cable (5), coax, Front Panel External Trigger to A8 Analog
IF Assy. P1
E4406-60139
W10 W10 Cable (8), coax, 7.5 MHz from A8 Analog IF P2, to A7
Digital IF, P1
8120-5022
W11 W11 Cable (3), coax, 21.4 MHz from A10 3rd Converter J5 to A8
Analog IF, J13
8120-5021
W12 W12 Cable (6), coax, TRIGGER IN from rear panel to A8
Analog IF, P4
8120-5053
W13 W13 Cable (20), coax, TRIGGER 1 OUT to A9 2nd LO, J12 8121-0153
W14 W14 Cable (30), coax, TRIGGER 2 OUT to A9 2nd LO, J11 8121-0153
W15 W15 Cable, semi-rigid, A9 2nd LO, J10 to Lowband, J5 E4440-20084
W16 W16 Cable (4), coax, 600 MHz from A11 Reference board P3 to
A9 2nd LO, J1
8120-5022
W17 W17 Cable (10), coax (with ferrites), A19 RYTHM highband
output to A10 3rd Converter J1
E4440-60371
W18 W18 Cable (7), coax (with ferrites), 321.4 MHz A20 Lowband
assy to A10 3rd Converter J2
E4440-60372
W19 W19 Cable (40), coax 321.4 MHz IF OUT from A10 3rd
Converter J4 to rear panel
8121-0149
W20 W20 Cable (50), coax, 50 MHz Cal signal from A10 3rd
Converter J7 to A14 Attenuator
8121-0156
W21 W21 Cable (90), coax, 10 MHz Out from A11 Reference Assy P2
to rear panel
8120-5053
W22 W22 Cable (70), coax, Ext Ref In from rear panel to A11
Reference Assy P1
8120-5053
W24 W24 Cable, semi-rigid, A21 SLODA to A12 Synthesizer E4440-20082
W44 W44 Cable (9), coax, IF IN from front-panel to A10 3rd
Converter J3 (Option AYZ)
E4440-60374
A12W2 A12W2 Cable, MMCX coax, 600 MHz Ref (325 mm) 8121-0151
