6-12 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Top Assemblies, All Options Except 080
Ref. Desig. Part Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange Assemblies” on page 6-5.
Qty Description
A4 0950-4599 1 Power supply assembly
A6 E8356-60006 1 Signal processing ADC module (SPAM) board
A8 E8364-60099 1 Fractional-N synthesizer board
A10 E8364-60136 1 Frequency reference board
A11 E8364-60137 1 Phase lock board
A12
E8362-60002
E8362-69002
1 Source 20
A14 E8364-60100 1 System motherboard
A15
E8364-60026
b
Replaces E8364-60025
b. If the CPU being replaced is the 500 MHz CPU, then you must also order a new hard disk drive. Refer to “Hard Disk Drive
Assembly” on page 6-78 for the part number. Photos of both CPU assemblies are located on page 7-79.
1 1.1 GHz CPU Replacement Kit
A40 Floppy disk drive
Refer to “Internal Hardware and Parts, All Options” on page 6-72.
B1 Fans
➀
USB hub board Refer to “Top Hardware, All Options” on page 6-68
