Display Commands

JITTer:SHADe

Command :DISPlay:JITTer:SHADe {{ON | 1}|{OFF | 0}}

Shows or removes the display of the jitter shade. The shade is the drop-down screen that is

used to display the jitter graphs. Because showing the shade takes some time, use this com-

mand to reduce measurement times in situations where testing would continually open and

hide the jitter shade.

Restrictions 86100C with Jitter Mode. Software revision A.04.10 and above including revision A.07.00.

When writing new code for software revision A.07.00 and above, use the recommended com-

mand “SINTegrity:SHADe” on page 11-10.

Example 10 OUTPUT 707;”:DISPlay:JITTer:SHADe ON”

Query :DISPlay:JITTer:SHADe?

Returned Format [:DISPlay:JITTer:SHADe] {{ON | 1}|{OFF | 0}}<NL>

LABel

Command :DISPlay:LABel “<text>” [,<row>[,<column>[,<text_color>[,<background>]]]]

Places a label on the graticule area of the display. You should periodically clear the labels

using the LABel:DALL command.

Arguments The string argument <text> is any series of ASCII characters enclosed in quotation marks.

<row> is 0 to 12, where 0 is the top row and the default. <column> is 0 to 61, where 0 is the

left column and the default. <text_color> is {CHANnel<N> | WHITe} Default is WHITe. <back-

ground> {OPAQue | TRANsparent} Default is TRANsparent.

Example 10 OUTPUT 707;":DISPLAY:LABEL""This is a label"""

LABel:DALL

Command :DISPlay:LABel:DALL

Deletes all displayed labels.

Example 10 OUTPUT 707;":DISPLAY:LABEL:DALL"

PERSistence

Command :DISPlay:PERSistence {MINimum | INFinite | <persistence_value> | CGRade | GSCale}

Sets the display persistence. The parameter for this command can be either MINimum (zero

persistence), INFinite, or a real number from 0.1 to 40, representing the persistence in sec-

onds, with one digit resolution, color grade, or gray scale. <persistence_value> is a real num-

ber, 0.1 to 40, representing the persistence in seconds.

Table 11-1. Persistence Values and Resolution

Persistence Value in Seconds Resolution (Step Size)

0.1 - 0.9 0.1s steps

1 - 10 1s steps
