18-39
Measure Commands
RESults?
Table 18-4. Result States
Code Description
0 Result correct. No problem found.
1 Result questionable. Current questionable values are returned.
2 Result less than or equal to value returned.
3 Result greater than or equal to value returned.
4 Result returned is invalid.
5 Result invalid. Required edge not found.
6 Result invalid. Max not found.
7 Result invalid. Min not found.
8 Result invalid. Requested time not found.
9 Result invalid. Requested voltage not found.
10 Result invalid. Top and base are equal.
11 Result invalid. Measurement zone too small.
12 Result invalid. Lower threshold not on waveform.
13 Result invalid. Upper threshold not on waveform.
14 Result invalid. Upper and lower thresholds are too close.
15 Result invalid. Top not on waveform.
16 Result invalid. Base not on waveform.
17 Result invalid. Completion criteria not reached.
18 Result invalid. Measurement invalid for this type of signal.
19 Result invalid. Signal is not displayed.
20 Result invalid. Waveform is clipped high.
21 Result invalid. Waveform is clipped low.
22 Result invalid. Waveform is clipped high and low.
23 Result invalid. Data contains all holes.
24 Result invalid. No data on screen.
25 Result invalid. Cursor is not on screen.
26 Result invalid. Measurement aborted.
27 Result invalid. Measurement timed-out.
28 Result invalid. No measurement to track.
30 Result invalid. Eye pattern not found.
32 Result invalid. Dark level is invalid.
33 Result invalid. Color grade/gray scale database has more than one source.
34 Result invalid. No RZ eye pattern found.
35 Result invalid. Excessive extinction ratio correction.
37 Result invalid. No TDR/TDT reference plane defined.
