FIN INSTALLATION
06 07
10 FOOT 6 STAND UP PADDLE BOARD
User’s Manual
10 FOOT 6 STAND UP PADDLE BOARD
User’s Manual
Slide metal plate forward, as shown above.
1
DO NOT USE EXCESSIVE FORCE
WHEN TIGHTENING SCREWS.
Caution
3
Insert Fin into fin box by inserting brass pin of Fin into the opening of
fin box, as shown above.
Slide Fin backwards into position,
as shown above.
Push Fin down, as shown above.
2
2.2
Fin
Fin Fin
Fin
2.1
2.3
Attach Fin to metal plate with
screw, as shown above. Do not
tighten yet.
Screw
Metal Plate
3
Adjust Fin position by sliding
forward or backwards to desired
position. Then tighten screw. Do
not over tighten screw.
4
Back
Metal Plate
Fin Box
