14
13
14
Position two upper deck rain
shields 97A above the front
two opening windows on the lefthand
side of the upper deck. Ensure that
the screw holes in the rain shields are
aligned with the holes in frames 85E.
Fix in place with two red BP screws on
each side (circled in light blue, inset).
13
Position an upper deck
rain shield 97A above
the rear opening window on the
lefthand side of the upper deck.
Ensure that the screw holes in the
rain shield are aligned with the
holes in frame 86D. Fix in place
with two red BP screws on each
side (circled in light blue, inset).
97A
97A
86D
BP
x2
BP
x2
97A
85E
85E
BP
x4
BP
x2
BP
x2
97A
